Technical parameter
Specifications
PHYSICAL CHARACTERISTICS
Dimensions (L*W*H)
110mm*83.5mm*75mm(4.33in*3.29in*2.95in)
Weight
275g
Configurations
Decoding
ENVIRONMENTAL
Temp
0° to 40°C / 32° to 104°F(operation)
-40° to 70°C /-40° to 158°F(storage
Humidity
5 - 90% (operation)
5 - 90% (storage)
Ambient light
Fluorescent light 4000lx max, direct sun light 80,000lx max ,white light 4000lx max
Shock drop test
1.2m drop onto concrete surface
ELECTRICAL
Interface
RS-232/USB HID KEYBOARD/USB VCP/
Voltage requirement
5VDC±10%
Current consumption
Max:190mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS array sensor
Sensor resolution
640X480 pixels
Aim light source
White LED
SCANNING PERFORMANCE
Min resolution
1D: 5mil(0.127mm)
Min.PCS value
〉25%UPC/EAN 13(13mil)
Field of View
53°(H),40°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D: Code 128,GS1-128,AIM-128,EAN-8,EAN-13,ISSN,ISBN,UPC-A,UPCE,Interleaved 2 of 5(ITF),Matrix 2 of 5,Industrial 2 of 5,Standard 2 of 5(IATA 2 of 5),Code 93,Code 11,Code 39,Codabar,GS1-Databar (RSS),Plessey,MSI-Plessey
2D: PDF417, Data Matrix, QR Code
