Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimensions
65mm x 61mm x 30mm(2.56in*2.40in*1.18in)
Weight
34g
Configurations
Decode
ENVIRONMENTAL
Ambient Light
Fluorescent light 1600 Lux max, direct sun light 80,000 lx max
Operating Temperature
0° to 50°C
Storage Temperature
-5°C to 55°C
Humidity
5 - 95% (operation) 5 - 95% (storage)
Shock drop test
1.2m drop onto concrete surface
ELECTRICAL
Interface
TTL-232/USB
Interface connector
0.5-12P FPC
Voltage requirement
DC 5V±5%
DC 3.3V±5%
Current consumption
Max:190mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS array sensor
Sensor Resolution
640X480 pixels
Aim light source
Red Bar LED
Light source
White LED
SCANNING PERFORMANCE
Decode angle
Tilt angle:±45°
Skew angle:±50°
Pitch angle:±180°
Field of View
53°(H),40°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D:Code 128,GS1-128,AIM-128,EAN-8,EAN-13,ISSN,ISBN,UPC-A,UPCE,Interleaved 2 of 5(ITF),Matrix 2 of 5,Industrial 2 of 5,Standard 2 of 5(IATA 2 of 5),Code 93,Code 11,Code 39,Codabar,GS1-Databar (RSS),Plessey,MSI-Plessey
2D:QR,PDF417,Data Matrix
